Kuvaus
Specifications Camera Image Sensor Min. Illumination 1/3″ Progressive Scan CMOS Color: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON) Shutter Speed Slow Shutter 1/3 s to 1/100,000 s Yes Auto-Iris Day & Night No IR Cut Filter Digital Noise Reduction Wide Dynamic Range 3D DNR DWDR Axis Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Lens Focal Length Aperture 2.8/4 mm F2.0 Focus FOV No 2.8 mm, horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 117° 4 mm, horizontal field of view: 75°, vertical FOV: 41°, diagonal FOV: 88° Lens Mount M12 IR IR Range Wavelength Compression Standard Up to 30 m 850nm Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG H.264 Type H.264+ Baseline Profile/Main Profile/High Profile Main stream supports H.265 Type H.265+ Main Profile Main stream supports Audio Compression Audio Bit Rate G.711/G.722.1/G.726/MP2L2/PCM 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) Video Bit Rate Audio Sampling Rate 32 Kbps to 8Mbps 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Environment Noise Filtering Yes Smart Feature-set Region of Interest Support 1 fixed region for main stream and sub-stream Image Max. Resolution Main Stream 2560 × 1440 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) Sub Stream 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Image Enhancement Image Settings BLC/3D DNR Saturation, brightness, contrast and sharpness are adjustable via client software and web browser Day/Night Switch Auto/Scheduled/Day/Night NetworkAlarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full Network Storage Protocols Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, UDP, Bonjour General Function Firmware Version One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter V5.5.60 API Simultaneous Live View ONVIF(PROFILE S,PROFILE G), ISAPI Up to 6 channels User/Host Up to 32 users 3 levels: Administrator, Operator and User Client iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ Interface Communication Interface On-board Storage 1 RJ45 10M/100M self-adaptive Ethernet port Built-in microSD/SDHC/SDXC slot, up to 128 GB Audio I/O Video Out 1 Built-in mic, mono sound No Alarm I/O Reset Button Wi-Fi No Yes Wireless Standards IEEE802.11b, 802.11g, 802.11n Frequency Range 2.412 GHz – 2.472 GHz Channel Bandwidth 20/40MHz Protocols 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS Transfer Rates 11b/g: 54Mbps, 11n: up to 150Mbps Wireless Range Up to 50 m (The performance varies based on actual environment) Power Consumption <20dBm General Operating Conditions -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) Power Supply 12 VDC ± 25%, Φ 5.5 mm coaxial plug power Power Consumption and Current 12 VDC, 0.5 A, Max: 6W Protection Level Material Dimensions IP66 Front cover: plastic, camera body: metal Camera: 69.7 mm × 67.9 mm × 171.4 mm (2.7″ × 2.7″ × 6.7″) With package: 216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.6″) Weight Camera: 372g (0.8lb) With package: 659g(1.5lb) Available Model: DS-2CD2041G1-IDW1(2.8/4 mm)
