Kuvaus
| Brand | HiWatch Hikvision |
| Video format | HDTVI/AHD/CVBS/IP |
| Video inputs | BNC, HDTVI / AHD / CVBS channels |
| Hybrid configuration | 4 BNC Channels and 1 IP Channel (1080p) |
| Video outputs | 1 HDMI Full HD, 1 VGA, 1BNC |
| Audio inputs | 1 RCA Channel |
| Audio outputs | 1 RCA Channel |
| Two-way audio | Reusing the audio input/output |
| Video/audio compression | H.264+ / H.264 / G.711u |
| Display resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Recording resolution | 1080p / 720p / WD1 / 4CIF /VGA / CIF |
| Main Stream Coding | 1080p (1~12 FPS) / 720p / VGA / WD1 / 4CIF / CIF (1~25 FPS) |
| Extra Stream Encoding | WD1 / 4CIF / 2CIF (1~12FPS) / CIF / QVGA / QCIF (1~25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Video analytics | VCA: Line crossing and area intrusion |
| Recording method | Manual, scheduled, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Indoor storage | 1 SATA 3.5″ HDD up to 6TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10M/100M (Ethernet) |
| Remote access | Web Browser, IVMS4500 Smartphone App and IVMS4200 PC Software |
| Food | DC 12V/15W |
| Dimensions/Weight | 45 (H) x 315 (Lg) x 242 (Fd) mm / 2 Kg |
